Description
HONDA = Proven Reliability
KEENE = World leader in portable mining and prospecting equipment. Family owned and operated since 1955.
PHP500 water pump is used primarily for gold dredges but has uses in many other applications such as aquaculture, fire fighting, removing weeds and sediments from water courses.
– up to 1890 Litres discharge per minute
– 60m Head pressure
Intake: 3″
Discharge: 2.5″, NPT thread
|
MODEL |
GX270 |
|
TYPE |
4-stroke, overhead valve, single-cylinder, horizontal 1″ threaded shaft |
|
BORE & STROKE |
77 x 58mm |
|
DISPLACEMENT |
270cm3 |
|
COMPRESSION RATIO |
8.2:1 |
|
NET POWER |
6.0kW (8.0HP) at 3,600rpm |
|
CONTINUOUS RATED POWER |
5.1kW (6.8HP) at 3,600rpm |
|
MAXIMUM NET TORQUE |
17.7Nm at 2,500rpm |
|
IGNITION SYSTEM |
Transistorised magneto ignition |
|
STARTING SYSTEM |
Recoil |
|
COOLING SYSTEM |
Forced-Air |
|
PTO SHAFT ROTATION |
Counter-clockwise (from P.T.O. side) |
|
FUEL CONSUMPTION AT RATED POWER |
2.5 L/h at 3,600rpm |
|
RECOMMENDED FUEL |
Unleaded |
|
LUBRICATION SYSTEM |
Splash |
|
RECOMMENDED OIL |
10W/30 API SG |
|
OIL CAPACITY |
1.1L |
|
FUEL TANK CAPACITY |
5.3L |
|
DIMENSIONS |
380 x 430 x 410mm |
|
DRY WEIGHT |
25kg, without pump |
