Honda GX270 Engine – KEENE PHP500 Water Pump

$2,604.35 +GST for NZ

Honda GX270 engine with powerful KEENE PHP500 water pump mounted.

All prices are subject to 15% GST for customers within New Zealand. International customers (shipping outside of NZ) are exempt from paying GST.

1 in stock

SKU: PHP5009 Category:

Description

HONDA = Proven Reliability
KEENE = World leader in portable mining and prospecting equipment. Family owned and operated since 1955.

PHP500 water pump is used primarily for gold dredges but has uses in many other applications such as aquaculture, fire fighting, removing weeds and sediments from water courses.

– up to 1890 Litres discharge per minute
– 60m Head pressure

Intake: 3″
Discharge: 2.5″, NPT thread

MODEL

GX270

TYPE

4-stroke, overhead valve, single-cylinder, horizontal 1″ threaded shaft

BORE & STROKE

77 x 58mm

DISPLACEMENT

270cm3

COMPRESSION RATIO

8.2:1

NET POWER

6.0kW (8.0HP) at 3,600rpm

CONTINUOUS RATED POWER

5.1kW (6.8HP) at 3,600rpm

MAXIMUM NET TORQUE

17.7Nm at 2,500rpm

IGNITION SYSTEM

Transistorised magneto ignition

STARTING SYSTEM

Recoil

COOLING SYSTEM

Forced-Air

PTO SHAFT ROTATION

Counter-clockwise (from P.T.O. side)

FUEL CONSUMPTION AT RATED POWER

2.5 L/h at 3,600rpm

RECOMMENDED FUEL

Unleaded

LUBRICATION SYSTEM

Splash

RECOMMENDED OIL

10W/30 API SG

OIL CAPACITY

1.1L

FUEL TANK CAPACITY

5.3L

DIMENSIONS

380 x 430 x 410mm

DRY WEIGHT

25kg, without pump
