PROLINE 4″ Dredge4″ Dredge w/Honda GX200 & HP400 pump & PCA10

Description

The Ultimate in Fine Gold Recovery

The light weight, portability and affordability of our 4″ dredge makes it appealing to both the weekend prospector and the serious dredger alike. Small enough to slide into a pickup, light enough to be packed into remote areas, the 4″ makes an excellent one man dredge. This model is equipped with pontoons that have increased stability over previous models, while remaining compact and lightweight. The frame remains essentially the same as previous models. It’s a sturdy bolt together design which allows the dredge to be disassembled into smaller components for ease of transport. Assembly requires only a few hand tools.

This dredge is equipped with a Honda GX200 engine and HP400 pump for additional power. The HP400 is a very efficient 3″x 2″ pump with a high flow, “progressive bite” five vane impeller. We highly recommend this engine/pump package for anyone who dredges to greater depths or at higher altitudes. This dredge is equipped with our “sure-flow” coupler, which essentially, eliminates all surface rock jams. Our unique one piece jet/flare assembly not only reduces down time caused by rock jams and is extremely light. The PCA10 compressor provides plenty of air even for two divers.

This dredge uses the highly acclaimed “wave classifier” which is proven to greatly enhance fine gold recovery by eliminating the problems associated with processing low grade sand. The classifier develops a pulsing, or “jigging,” action which prevents the dredged material from loading up under it. By shedding the low grade particles, the fine gold can drop out of suspension earlier and accumulate under the classifier where it is safe from the turbulence and disturbance caused by the larger rocks traveling through the sluice. The rear portion of the sluice box utilizes “Hungarian” riffles for maximum efficiency and the dredge is equipped with Nomad matting for the ultimate in fine gold recovery.

4″ Dredge w/Honda GX200 & HP400 pump & PCA10

SPECIFICATIONS

• Engine: Honda GX200
• Pump: HP400
• Sluice Box: 16″ x 48″
• Dredge Hose: 4″ x 15 ft.
• High Pressure Hose: 2″ x 72″
• Intake Hose: 3″ x 42″ for Honda GX200
• Flotation: 4 polyethylene floats 13″ X 46″ X 74″
• Air Compressor: PCA10
• Swivel Tip (at no extra cost)
• Weight: 97kg

Please note that instead of the T80 as pictured the dredge will be supplied with a PCA10 compressor and the dredge floats might be blue instead of green.
