Description
Specifications:
- Package dimensions: Width 406 mm; Length 660 mm; Height 432 mm
- Assembled dimensions: Width 340 mm; Length 490 mm; Height 510 mm
- Firebox size: Width 225 mm; Length 320 mm; Height 180 mm
- Smoke pipe diameter: 65 mm
- Length of one smoke pipe segment: 300 mm
- Production materials: Stainless steel AISI 430, fire-resistant glass – 4 mm thickness
- Gross/Net weight: 18.7 kg
Introducing our small stove “Caminus S” for heating winter camping tents and cooking. The main feature of the “Caminus S” stove is that the side walls are made from heat-resistant ceramic glass. This glass offers superior heat emission compared to conventional steel and also serves as an additional light source inside the tent. The working temperature of the glass reaches up to 750° C. The transparent glass stove walls are convenient to maintain adequate levels of wood or briquettes inside the firebox.
FEATURES:
1. Safety
The “Caminus S” stoves are equipped with 4 protective metal shields.. These shields protect users from accidentally touching hot surfaces. The lower shield protects the tent floor from heat, the side shields protect the tent wall behind stove from heat, and they also protect the ceramic plates during transportation and storage.The coil type spark arrestor is built in the upper side of firebox. It splits the firebox into two areas. In the lower main section, there are burning and heat emission processes. The upper section is where the after-burning process occurs. The spark arrestor increases the efficiency of the stove, evenly heats the cooking surface, and protects the outer layer of the tent from sparks.
What happens if the stove is used without a spark arrestor? Sparks can fly out of the smoke pipe, fall onto the tent, and burn holes in it, so the tent can no longer keep the interior warm or protect you from the rain. Unfortunately, many stove manufacturers don’t take this into consideration. We manufacture our stoves using the safest and latest safety standards.
The stove package includes 2 additional metal plates of the same size as ceramic glass plates. These plates can be used instead of glass in case the glass is accidentally broken.
Removable aluminium legs are designed for stable and safe positioning of the stove.
The deflector helps protect the smoke pipe from rain and improves smoke ventilation.
The air damper regulator of the firebox cap regulates the intensity of burning and regulates the temperature inside the tent.
Carrier handles are located on the end walls, which make cleaning ash from the stove easier.
A smoke detector included in the package will sound an alarm if smoke gets inside the tent.
2. Manufacturing materials
The “Caminus S” stove is manufactured from several materials. The stove body is made from 1 mm thick high-tech stainless steel AISI 430.
The heat-resistant glass is 4 mm thick and made in Germany. Areas of contact between the glass and metal are equipped with heat-resistant sealing. Sealing prevents smoke from getting inside the tent and prevents damage to the glass.
Stove integrity is enhanced by argon welding on the bottom side. We also offer a three-year warranty on our “Caminus” stove.
Our product is manufactured from high quality materials BUT is not designed to be used continuously 24/7 without any cooling intervals.
Video review on the Ryan outdoors channel on YouTube. More than 5k subscribers!
Packaging:
- Stove
- Smoke pipe segments – 7 pieces
- Deflector
- Stove legs case – 1 piece
- Removable metal shields – 2 pieces
- Spare metal shields – 2 pieces
- Smoke detector – 1 piece
- Pair of gloves – 1 piece
- Fireproof mat – 1 piece
- Carrier bag – 1 piece
- User manual – 1 piece
Carrier companies have damaged many of our stoves during shipping. Therefore, we have developed a sturdy wooden box for our stoves. Since the stove should meet strict safety requirements, it must retain its shape and not be subject to severe impact during shipping.
Advantages of buying from us:
1. The stove safely reaches the customer thanks to the wooden shipping box.
2. The stove can be stored and transported in the box to any camping site.
