Propane Furnace – FB1S – Devil Forge = thicker insulation than FB1SB

$781.74 +GST for NZ

The FB1S metal melting furnace is not only powerful and portable, but is also of the highest quality.

All prices are subject to 15% GST for customers within New Zealand. International customers (shipping outside of NZ) are exempt from paying GST.

2 in stock

SKU: FB1S Category: Tag:


It has been specifically designed for jewelers, metal smiths and refiners with a robust DFP burner. This high temperature, fast melting furnace is capable of melting metals up to a temperature of 1450°C (2642 Fahrenheit).

Specification FB1S:

  • Burner: DFP 1pc, which will work with a) Butane b) Propane c) mixture of Butane & Propane d) LPG but it won’t work with natural gas.
  • Furnace Body Constructed of: steel 16 gauge (1.5mm), the shell is lightweight
  • Chamber Dimensions: 100mm x 185mm (ØxH); crucible size recommendations see below
  • Outside Dimensions: 200mm x 300mm
  • Weight: 11kg

The furnace interior is fully lined with 1 inch of ceramic wool and 1 inch refractory cement. It does not have to be treated with rigidizer prior to its use like the FB1SB model. However, it will have to be dried (seasoned) according to the instructions provided here. Due to the superior insulation no heat resistant brick is supplied for the base.

This furnace is capable of melting gold, silver, copper, aluminium, brass, bronze, cast iron and many other metals.

It will fit crucibles with the following maximum dimensions:
Ø ~ 95mm, Height ~ 170mm
Ideal size and type is the A1 Salamander crucible

Due to the smaller chamber size it is best to use our 19” bent crucible tongs

To get started you will also need:
• 2 to 9 kg LPG or equivalent gas cylinder fitted with a standard QCC-1 connection.
• Crucible
• Set of tongs
• Leather gloves
• Safety glasses

The below videos are a great demonstration on how to setup a Devil-Forge furnace after unpacking. They clearly show how easy the whole process is and how effective you can melt all sorts of metal. The furnaces used may not necessarily show the same furnace which is advertised in the above listing.
